Serial numbernameModel/Specificationquantitybrandremark1Main engine motor15KWoneDongyuan2Rotating motor3.75KWonecustom3Frequency changer18.5KW/5.5KWTwo setsJoint stock4Lapping drum size1300*300*400MM length width height4 groups /8 facesBaosenThe inner bucket size can be freely adjusted in width5Exte......
Serial number | name |
Model/Specification |
quantity |
brand |
remark | ||
1 | Main engine motor | 15KW | one | Dongyuan | |||
2 | Rotating motor | 3.75KW | one | custom | |||
3 | Frequency changer | 18.5KW/5.5KW | Two sets | Joint stock | |||
4 | Lapping drum size | 1300*300*400MM length width height | 4 groups /8 faces | Baosen | The inner bucket size can be freely adjusted in width | ||
5 | External dimension of equipment | 3100*1800*2100MM length width height | A set | Baosen | |||
6 | Control system | PLC control | A set | Mitsubishi | |||
7 | bearing | TR | ten | TR | |||
8 | septum | Imported PU adhesive | A set | Baosen | custom | ||
9 | Principal axis | 40 cr | A set | Baosen | Heat treatment | ||
10 | weight | 4.5 tons | A set | ||||
Advantage remarks |
1. The grinding barrel is lined with DuPont PU adhesive, which can prevent the product from abrading and bruising and is durable and wear-resistant. |
||||||
2. The width of the partition in each grinding barrel can be freely changed according to the size of the product, so as to achieve universal use of one machine. |
|||||||
3. PLC control, simple operation, safe and stable, one-button start, one person can operate multiple equipment. | |||||||
4. Do not need to use fixture fixture to fix the product, save manual and cumbersome tooling design clamping, directly put the product into the grinding bucket can be polished, Convenient and fast, one-click start, fool operation production. |
|||||||
5. Plant particles smooth, environmental protection and pollution-free, good production environment, high rotational number dry smooth, polished surface bright clean and uniform. |
|||||||
6. The surface of the product after centrifugal positive and negative polishing is uniform, bright and fine without dead corners, and it is especially friendly for various special-shaped parts. |
|||||||
7. Each grinding drum cover is equipped with a dust discharge mesh, the dust generated by the smooth will be discharged with the rotation of the grinding drum, will not let the particles stick, keep the particles clean, extend the service life of the particles. |
|||||||
8. The rear panel of the equipment is provided with air extraction holes, which can be equipped with dust removal equipment, and the top of the machine is equipped with two exhaust fans for ventilation and heat removal. |
|||||||
9. The side of the operation door is equipped with a large plate and a small bucket rotating button, which is convenient for taking and placing pieces or checking what is needed, and is more humane. |
|||||||
10, the machine for non-human damage free warranty for one year, lifelong maintenance. (Except for wearing parts, inner rubber drum and partition belong to wearing parts) | |||||||
BC-1300-192 Grinding groove cell structure parameters: | |||||||
Serial number | Grinding tank | specification | quantity | remark | |||
1 | Maximum partition size of grinding tank | Slot size: 580*270*200MM (length, width and height) | 16 (PCS) | ||||
2 | Grinding groove commonly divided size | Slot size: 270*100*200MM (length, width and height) | 96 (PCS) | ||||
3 | Grinding groove commonly divided size | Slot size: 135*100*200MM (length, width and height) | 192 (PCS) | ||||
4 | Minimum partition size of grinding tank | Slot size: 80*100*200MM (length, width and height) | 288 (PCS) | Rarely used, the grid is too small to take the product, and the grid small polishing time will be long |
