White Horse Speed Stabilizer

YueLi invites you to visit our factory to purchase the newest, best-selling, affordable, and high-quality White Horse Speed Stabilizer. We are looking forward to working with you.

Send Inquiry

Product Description

White Horse speed stabilizer

Focus on quality We are the right choice for you

White Horse Speed Stabilizer

Six core advantages to be different

1. High-frequency buffer 2. Prevent oil leakage 3. Import oil seal

4. Complete specifications 5. Quality assurance 6. Fast delivery

* Speed control stroke: 12.7mm, 25.4mm, 50.8mm, 76.2mm 4 kinds.

* Propulsive force range: 12 N ~ 5,450 N. * Ambient temperature: 57 ℃.

★ Speed control travel do not exceed the effective speed control travel, please be able to stop before the effective speed control travel 0.7~ 0.8mm.

★ It is strictly forbidden to paint on the axis or damage caused by the device.

★ Note that the ambient temperature should not exceed 57 ℃.

★ Please pay attention to the failure caused by the steel impact of the moving object to the destruction of the axis and the excessive eccentric Angle.

★ Please note that the strength of the fixed iron plate must be higher than 1.5 times the propulsion force.

★ If there are corrosive gases, small particles, fine glass chips, fiber dust, fine metal particles, more astringent oil and cutting fluid, please contact us in advance, our company can provide professional technical treatment solutions.

White Horse Speed Stabilizer

The precision speed stabilizer is designed to control the speed and move steadily, so it cannot withstand the damage caused by the high impact kinetic energy of the object when it moves.

If the design of the machine is to achieve rapid production efficiency, then we recommend that you use the product (Cushion-Start), which can meet the needs of customers and avoid unnecessary equipment failures during use.

Withstand the impact of instant contact with the shaft: Mini-K 12.7 or 25.4 mm (18N)

Slimline 12.7 or 25.4 mm (88 n) 50.8 or 76.2 mm (44 n)

Super K 101.6 or 152.4 mm (44 n)

Fine workmanship of real materials

Good materials make stable properties

Stainless steel piston rod!!!!

White Horse Speed Stabilizer

Stainless steel piston rod

Stainless steel, internal link spring, automatic reset stroke

Pressure and tension resistant housing

Stainless steel, internal link spring, automatic reset stroke

mported oil seal is not easy to leak oil

Internal link ZE ZE, can automatically reset the travel

White Horse Speed Stabilizer

Model	category	journey	The minimum operating force required by the piston rod in the full stroke	Piston rod cartridge Spring return point Require strength	Extinction of external force Piston response Controlled time	The speed is adjusted to the maximum load required for the piston rod to move 1 inch per second	The speed is adjusted to the maximum load required for the piston rod to move 4 inches per second	The catch is set to the time required for the slowest piston rod to complete the journey
Model	category	journey		Piston rod cartridge Spring return point Require strength				Load 1000 1bs	Load 500 1bs	Load 100 1bs
1001-31-1/2	Ultrafast type	1/2 in	5 1 bs	4 1 bs	.015 sec	6 1 bs	10 1bs	0.5 sec	1 seC	10 sec
1003-31-1/2	Fast type				.020 sec	9 1 bs	19 1bs	4 seC	9 sec	75 sec
1002-31-1/2	Normal form				.031 seC	11 1 bs	33 1bs	8 sec	18 seC	150 sec
1004-31-1/2	Slow type				.186 sec	30 1 bs	90 1bs	38 sec	90 seC	12.5 min
1001-31-1	Ultrafast type	1in	5.1 bs	4 1 bs	.030 sec	6.1 bs	10 1bs	1 sec	2 sec	20 sec
1001-31-1	Fast type				.041 sec	9.1 bs	19 1bs	8 sec	18 sec.	150 sec
1001-31-1	Normal form				.063 sec	11.1 bs	33 1bs	15 sec	35 sec	5 min
1001-31-1	Slow type				.378 sec	30.1 bs	90 1bs	75 sec	180 sec	25 min
1001-31-2	Ultrafast type	2in	5 1bs	4 1bs	.052 sec	6 1bs	10 1bs	2 sec	5 8eC	40 sec
1001-31-2	Fast type				.070 sec	9 ibs	19 1bs	15 sec	35 sec	5 min
1001-31-2	Normal form				.106 sec	11 1bs	33 1bs	30 sec	70 sec	10 min
1001-31-2	Slow type				.730 sec	30 1bs	90 1bs	150 sec	6 min	50 min
1001-31-3	Ultrafast type	3in	5 1b5	4 1bs	115 seC	6 1bs	101bs	3 sec	7 sec	60 sec
1001-31-3	Fast type				.155 sec	9 1bs	19 1bs	23 sec	55 seC	7.5 min
1001-31-3	Normal form				235 se0	111 bs	33 1bs	45 sec	105 sec	15 min
1001-31-3	Slow type				1.62 0 sec	30 1bs	901bs	225 sec	9 min	75 min
